Verifone P630 PIN Pad - (New)
Verifone P630 PIN Pad - (New)
Couldn't load pickup availability
For injections or if you have any questions please call us at (470) 432-9104.
The Verifone P630 base model brings the same advanced Android 10 platform, 3.5" color touchscreen, and PCI PTS 6.x security as the Plus model at a more accessible price point. Accepts all major payment types including NFC/CTLS, EMV, and magstripe, with support for Advanced Payment Methods. Uses existing Engage P400 cabling and stands for easy, cost-effective migration from older deployments.
An optional external USB camera adds barcode and QR scanning capability at the counter. With dual-band Wi-Fi and Bluetooth 4.2 built-in, the P630 deploys wirelessly right out of the box. IP53-rated for splash and dust protection, and PCI PTS 6.x certified for above-average security at this price tier. For injections or questions call us at (470) 432-9104.
Key Features:
• 3.5" Color Touchscreen: Full-color capacitive display for brand promotion and customer engagement.
• Backlit Tactile Keypad: 15-key backlit keypad alongside the touchscreen for reliable PIN entry.
• Buzzer + Speaker: Full multimedia audio for transaction confirmation and customer engagement.
• Optional Barcode Scanner: External 0.3MP USB camera option adds barcode and QR scanning at the counter.
• Android 10: Engage VOS3 platform for a modern, flexible PIN pad experience.
• PCI PTS 6.x: Advanced security certification — above standard for this price range.
• All Payment Types: NFC/CTLS, EMV chip, magstripe, and Advanced Payment Methods.
• P400 Compatible: Uses existing Engage P400 cabling and stands — no new hardware on migration.
• Wi-Fi + Bluetooth: Dual-band Wi-Fi and Bluetooth 4.2 built-in.
• Anti-Theft Slot: Physical security for permanent retail deployments.
• IP53 Rated: Splash and dust resistance.
• Cloud Services: Verifone Cloud Services ready.
• 2 SAM + Optional 3rd SAM Slot: Flexible processor configuration support.
• Accessories: Mounting plate, mounting pole, privacy shield, and stylus all available.
Specifications:
|
Operating System |
Verifone Secure OS, Engage VOS3 | AVOS based on Android 10 |
|
Processor |
ARM Cortex A53, Quad Core, 1.3 GHz |
|
Memory |
1GB RAM + 8GB Flash | Micro SD |
|
Display |
3.5" Color LCD | Capacitive Multi-touch | 320x480 HVGA |
|
Multimedia |
Buzzer | Speaker |
|
User Interface |
Backlit Keypad | Tactile 15 Key Keypad |
|
Camera | Barcode Scanner |
Barcode + OCR + QR Decode | Optional External 0.3MP Fixed Focus |
|
Card Readers |
Magstripe ISO 7810/7811/7813 | Smart Card EMVCo Approved |
|
Contactless |
EMVCo Approved | MiFare | Supports Advanced Payment Methods | Major NFC/CTLS Schemes |
|
Connectivity |
Bluetooth 4.2 | Wi-Fi 2.4GHz+5GHz 802.11 a/b/g/n |
|
Ports |
LAN 10/100 Base-T | RS232 | USB RJ45 for Host/Device | Verifone 28-Pin PIN pad |
|
Security |
PCI PTS 6.x Approved | Anti-theft slot |
|
Power |
9-12V, 1A, DC Jack |
|
Physical |
170mm L x 80mm W x 33mm H | 305g |
|
Environmental |
Operating: -10°C to 50°C (14°F to 122°F) | Storage: -20°C to 60°C (-4°F to 140°F) | Humidity: 5-90% Non-condensing | IP53 | IK04 |
|
Other |
2 SAM + Optional 3rd SAM | Anti-Theft Slot | Accessories: Mounting Plate, Mounting Pole, Privacy Shield, Stylus |
